Bulk Cement Tanker Bulk Cement Tank Semi Trailer Bulk Cement Tankers for Sale

Axle Number : 3 Axles

Tire Number : 12 Linglong Tyres

Self-dumping : Not Self-dumping

ABS Anti-lock Braking System : ABS Anti-lock Braking System

Material : Steel

Condition : New

Landing Gear : Fuwa 28t Loading

Rim : 8.25-20/9.0-20

Tyre : Linglong,Double Coin,11.00r20/12.00r20

Size : 12000X2500X3800mm

Axles Brand : Fuwa, BPW 13t/16t/20t

Ladder : with Minimum 130 mm Toehold Clearance

Discharge Speed : 1.2-1.5t/mm

Working Pressure : 0.2MPa

Residual Rate : Under 0.2%

Discharge Height : Hegher Than 25m

Transport Package : Bulk Cargo/Roro/Flat Rack

Trademark : FOREVER

Origin : China

Supply Ability : 2000

Type : Semi-Trailer

Load Capacity : 50T

Certification : ISO9001, CCC

Wheel Base : 9000-10000mm

Tread : 1820mm

Grade : Heavy Duty

Customization : Available | Customized Request

Contact Now

Product Description

Company Info.

Customer Question & Answer

Ask something for more details

(0)

Basic Info.

Axle Number

3 Axles

Tire Number

12 Linglong Tyres

Self-dumping

Not Self-dumping

ABS Anti-lock Braking System

Material

Steel

Condition

New

Landing Gear

Fuwa 28t Loading

Rim

8.25-20/9.0-20

Tyre

Linglong,Double Coin,11.00r20/12.00r20

Size

12000X2500X3800mm

Axles Brand

Fuwa, BPW 13t/16t/20t

Ladder

with Minimum 130 mm Toehold Clearance

Discharge Speed

1.2-1.5t/mm

Working Pressure

0.2MPa

Residual Rate

Under 0.2%

Discharge Height

Hegher Than 25m

Transport Package

Bulk Cargo/Roro/Flat Rack

Trademark

FOREVER

Origin

China

Production Capacity

2000

Product Description

Bulk Cement Tanker Bulk Cement Tank Semi Trailer Bulk Cement Tankers for Sale

MAIN PERFORMANCE

Main Specification
Tank Body
Type	3 Axle 30cbm-126cbm Bulker/Bulk Cement/Powder Transportation Tanker/Tank Truck Semi Trailer
Shape	V type(single cabin or double cabin) / Multi-cabin
Volume	30cbm-126cbm
Loading capacity(kg)	30t-135t
Dimension	13500x2500x3800mm
Tanker Body Material	5mm / Q235 carbon steel
End Plate	6mm or 5mm /Q235 carbon steel
Diesel Engine	WEICHAI HUAFENG ,TianHe 4102 engine
Compressor	BOHAI brand( 12m³-16m³ 37 KW,0.2Mpa. 1000r/Min(12m3/minute)
Manhole Cover	500mm manhole cover. 1 sets with 1 breath valve
Discharging Valve	Diameter is 3 or 4 inch
Discharging Pipe	3 or 4 inch rubber hose, 1pcs, 6m/each
Walking board	Skid resistance
Chassis
Main Beams	Welding Design ,Q345 carbon steel
Axles	FUWA, BPW 13T/16T/20T strong axles
Landing Gear	FUWA, JOST brand, 28t loading
Leaf Spring	90(W)mm x 13(Thickness)mm,10/10/10 pieces
Tyre	Linglong, Double Coin brand 11.00R20, 12.00R20
Rim	8.25-20 or 9.00-22.5
Braking system	WABCO RE 6 relay valve; T30/30+T30/T30 Spring brake chamber ; 45L air tanks.
Side marker lamp	LED type
ABS	KOMEE ABS braking system
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
Accessories	TOOL BOX (BOX ONLY)---PROVIDED WITH THE TRAILER TWO SPARE WHEEL HOLDER(WINCH),BUT NO SPARE TYRES
Shipping Terms	By Bulk Cargo ,RORO or bus deck container ,frame container

I.Application and the Technical Highlights

***This series bulk cement tanker truck semi trailers are tank-style designed, is suitable for the transportation of liquid products, bulk materials, and bulk cement.
***Mainly suitable for the MID/Long distance transportation of bulk cement, coal ash, lime power, mineral power, fly ash and other power material with the diameter around 0.1mm.
*** Equipped with fluidized bed, intake control system, and thrusting control system to ensure the air compressor and the perfect match of tank; Residual rate is low, safety performance is high, easy to operate; Good performance of simple structure, convenient maintenance, vulcanization.
***Working pressure 0.2Mpa, Discharge speed 1.2-1.5t/mm, Residual rate≤2‰,Discharge height≥25m.
***Our bulk cement tank semitrailer will not only reduce the loss rate of cement power material, but also improve the loading and unloading efficiency,
***BPW, FUWA or Certificated Chinese Axles
***ABS brake system
***WABCO Vehicle Control System
***JOST ,FUWA or Chinese brand parking leg and king pin
***Air and Mechanical Suspension
***Strengthen the Chassis Instructure

Bulk Cement Tanker Bulk Cement Tank Semi Trailer Bulk Cement Tankers for Sale

Bulk Cement Tanker Bulk Cement Tank Semi Trailer Bulk Cement Tankers for Sale

II.Distinguishing Features

---We adopt the advanced 3D design software to design our effective tank volume larger and rational design .Tide area fluidized bed with large angle of tank makes unloading faster and with lower residual .
---We adopts high strength wear-resistant steel 620JJ as tank body material .This material 620JJ is three times as strong as the others. the trailer adopted this material uses for more than 10 years in general , the service life is two times as length as ordinary steel material 's trailer .
---We adopt the felt-board machine for welding the tank body.It realized one-time forming .The high quality welds ensure no air leak,and with long service life .
---Steel frames are built with top-class hot rolled or rolled steel plate, automatic welded longitudinal beam and adopting advanced sanding and painting process as preliminary treatment.

Bulk Cement Tanker Bulk Cement Tank Semi Trailer Bulk Cement Tankers for Sale

III.The Advantages
1.The shape of cement tank adopts V-type filling structure, adopts the latest fluidized structure, has larger loading volume, lower center of gravity, less material residue, simple structure, faster discharge speed, much easier to operate and service.
2.The optional of the cement bulk tank semitrailer according to the customer's requirement, we have single compartment; double compartments; three compartments; three-dimensional compartments structure..
3.The material of the cement bulk tanker body is Carbon Steel.Our new Aluminum Alloy cement bulk tank trailer is our new product. The Advantage is light weight and heavy loading capacity.
4.The body of the cement tanker is mainly composed of a cylinder body, a tank upper feed inlet, a fluidized bed, a discharge pipe assembly, an air intake pipe and other accessories.
5.The advantage of our cement tank body is high overall strength, good rigidity, good pressure.
Bulk Cement Tanker Bulk Cement Tank Semi Trailer Bulk Cement Tankers for Sale

IV. Classification

Bulk Cement Tanker Bulk Cement Tank Semi Trailer Bulk Cement Tankers for Sale

V.Option

VI. Guarrantee For The Parts Of The Tanker Traielr:

ITEM NAME			WARRANTY	ITEM NAME		WARRANTY
MAIN FRAME	FRAME		1 YEAR	RUNNING GEAR	AXLE	6 MONTHS
	SUSPENSION		6 MONTHS		AXLE BEARING	3 MONTHS
	KING PIN		1 YEAR		WHEEL HUB	3 MONTHS
	BALANCE ARM		3 MONTHS
ITEM NAME			WARRANTY	ITEM NAME		WARRANTY
BRAKING DEVICE		BRAKE DRUM	3 MONTHS	SUPPORT DEVICE	LANDING GEAR	6 MONTHS
		BRKE CHAMBER	3 MONTHS		SPARE WHEEL CARRIER	6 MONTHS
		AIR RESERVOIR	6 MONTHS
ITEM NAME					WARRANTY
OTHERS		LEAF SPRING			3 MONTHS
		BRAKE CHAMBER DIAPHRAGM			3 MONTHS
		EMERGENCY RELAY VALVE			3 MONTHS
		BRAKE SHOE			3 MONTHS
		RELAY VALVE			3 MONTHS

VII. DEALING PROCESS

1. You send us an inquiries on your desired trailer through our contact information.
2. We shall reply you in 12 hours after we received our inquiry.
3. We will negotiate the detail of the trailer on your requirement.
4. Confirmed on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. The Manufacturig process with updated news.
9. The Production completement.
10.Balance payment .
11.Arrange Shipment and Custom Clearance
12. A/S service for 1 year.
